ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
5.1 Measurement of Transmission Characteristic (2 Trace Display)
5-9
Set channel 2 to the phase and channel 1 to the linear magnitude.
[FORMAT] {PHASE}
[CH 1] {LIN MAG} [SCALE] {AUTO SCALE}
The display on the screen is as follows.
This corresponds to the linear magnitude/phase measurement (overlap display) of
sub-section 5.1.1.
Figure 5-7 Linear Magnitude/Phase Measurement (Split Display)
8
