R3765/67G Series Network Analyzer Operation Manual

5.4 Multi-marker List Display

5-30

Display marker list.

All the marker data are displayed.

{Return} {MKR LIST ON/OFF}

By the operation above, the marker and the list are displayed as follows.

Figure 5-26 Display of Multi-marker List
