R3765/67G Series Network Analyzer Operation Manual
3.6 Measurement Samples of Simple Reflection Characteristics
3-25
3.6.3 Measurement by various formats
Here describes about measurement methods by various formats of reflection measurement
(return loss, reflection coefficient, standing wave ratio, S parameter and impedance).
Return loss (LOG MAG format setting) measurement
Adjust the scale to see the display trace (magnitude ) easily.
[SCALE] {AUTO SCALE}
Letting the reflective coefficient = ρ (= reflective signal/incident signal), the return loss
is represented with the following equation.
Return loss = -20log ( ρ )
The display on the screen (return loss) is as follows.
Figure 3-22 Return Loss Measurement
