R3765/67G Series Network Analyzer Operation Manual
3.6 Measurement Samples of Simple Reflection Characteristics
3-21
(2) BG/CG type
Figure 3-18 Setup for Reflection Characteristic Measurement
(BG/CG Type)
• DUT of this measurement sample is a band pass filter of center frequency of 880MHz.
• All the displays used on the screen are display samples of R3767CG.
The displayed contents of input port in the upper left portion of the screen are different
depending on the model.
The display of each type is as follows.
RFL : REFLECTION
AG type BG type CG type
A/R RFL S11
TEST PORT 2TEST PORT 1
DUT
R3765BG/67BG/65CG/67CG
