R3765/67G Series Network Analyzer Operation Manual
7.4 RESPONSE Block
7-18
7.4.5 Display Layout
(1) Examples showing that the marker list is OFF and in the superposition mode
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: OFF CH1
SPLIT CH: OFF
CH1 SUB MEAS:
OFF
CH2 SUB MEAS:
OFF
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: ON CH1
SPLIT CH: OFF CH2
CH1 SUB MEAS:
OFF
CH2 SUB MEAS:
OFF
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: OFF CH1
SPLIT CH: OFF CH3
CH1 SUB MEAS:
ON
CH2 SUB MEAS:
OFF
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: ON CH1
SPLIT CH: OFF CH2
CH1 SUB MEAS: CH3
ON
CH2 SUB MEAS:
OFF
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: OFF
CH1
SPLIT CH: ON
CH1 SUB MEAS: CH3
ON
CH2 SUB MEAS:
OFF
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: ON CH1 CH2
SPLIT CH: ON
CH1 SUB MEAS: CH3
ON
CH2 SUB MEAS:
OFF
