R3765/67G Series Network Analyzer Operation Manual
7.4 RESPONSE Block
7-16
7.4.4 Four Screen Display and Display Selection Information
The 2 channels simultaneous display can be performed.
Each channel has a sub-measure screen display, so that four-screen-display in total can be per-
formed.
Also the selection of the trace data, the coordinate display ON/OFF and the label input can be
performed.
The Setting and the Explanation
Press the [DISPLAY] to call the display menu. (Refer to section A.4.)
Display menu
• Display menu (1 of 2)
{DUAL CH ON/OFF} : Selects ON/OFF of the two channels simultaneous
display (overlap display). (Note)
{SPLIT CH ON/OFF} : Selects ON/OFF of the display split in two, the upper
part and the lower part (split display). (Note)
{DISPLAY [ ]} : Calls the trace data selection menu to select whether
measurement data, memory data and both data is
displayed. (Refer to sub-section 7.4.6.)
{DEFINE TRACE [ ]} : Calls the trace operation menu.
Four fundamental operations are executed for the
measured data and the memory data. (Refer to sub-
section 7.4.7.)
{DATA → MEMORY} : Enters data into memory.
When two-trace display has been selected, data
toggled by {TRACE 2nd/1st} is entered.
{CONVERSION [ ]} : Calls the parameter selection menu to convert the
measured data into an impedance or an admittance.
(Refer to of sub-section 7.4.1.)
{TRACE 2nd/1st} : Selects between the 1st trace and the 2nd trace.
Note: Depending on which SUB MEAS is chosen, the ON/OFF settings of SPLIT CH
and DUAL CH or the status of the marker list, the screen display varies.
• Display menu (2 of 2)
{GRATICULE ON/OFF} : Selects ON/OFF of the coordinate display.
* This function cannot be set for the Smith chart or the
polar coordinates.
{LABEL} : Calls the label menu for entering the label. (Refer to
sub-section 7.4.8.)
{COLOR} : Specifies the color of the trace and the marker. (Refer
to sub-section 7.4.9.)
{DEFAULT COLOR} : Sets all color setting to default.
1
2
3
To Next Page
