R3765/67G Series Network Analyzer Operation Manual
7.4 RESPONSE Block
7-10
7.4.1 Setting Input and Parameter Conversion
Selects the receiver section input port.
With the sub-measure screen, the input port can be set in the condition of sub-measure ON.
The data which is measured in the selected input port is a “complex data”. This data is also for-
matted such as the magnitude, phase, group delay. Data before formatting can be changed to
impedance, admittance, reverse S parameter.
The Setting and the Explanation
Press the [MEAS] to call the measurement menu. (Refer to section A.4.)
Measurement menu
• For R3765CG/67CG
{S11 REFL FWD} : Sets the input port to S
11
REFL FWD.
{S21 TRANS FWD} : Sets the input port to S
21
TRANS FWD.
{S12 TRANS REV} : Sets the input port to S
12
TRANS REV.
{S22 REFL REV} : Sets the input port to S
22
REFL REV.
{S11&S21 FWD} : Sets the input port to S
11
&S
21
FWD.
{S22&S12 REV} : Sets the input port to S
22
&S
12
REV.
{SUB MEAS ON/OFF}: Sets the ON/OFF of sub measurement.
{CONVERSION [ ]} : Calls the parameter menu for converting the measured
data to an impedance, admittances or reverse S
parameters. (See step .)
• For R3765AG/67AG
{A/R} : Sets the input port to A/R.
{B/R} : Sets the input port to B/R.
{SUB MEAS ON/OFF} : Sets the sub-measure ON or OFF.
{CONVERSION [ ]} : Calls the parameter converting menu to covert the
measured data to impedance or admittance. (See step
.)
• For R3765BG/67BG
{REFLECTION} : Sets the input port to REFLECTION.
{TRANSMISSION} : Sets the input port to TRANSMISSION.
{REFL & TRANS} : Sets the input port to REFL & TRANS.
{SUB MEAS ON/OFF} : Sets the sub-measure ON or OFF.
{CONVERSION [ ]} : Calls the parameter converting menu to convert the
measured data to impedance or admittance. (See step
.)
• When the R3765CG or R3767CG is used with OPT11/OPT14:
{S11(PORT1)} : Sets the measurement parameter to S11.
1
2
3
3
3
To Next Page
