R3765/67G Series Network Analyzer Operation Manual
5.1 Measurement of Transmission Characteristic (2 Trace Display)
5-3
In order to change the object of scale change to the second trace (phase), select 2nd
by “TRACE”.
The reference line is also switched to the second trace’s.
Then the operation of marker also becomes effective to the second trace.
{TRACE 2nd/1st} {AUTO SCALE}
The display on the screen is as follows.
Figure 5-2 Auto-scale of the Second Trace of Magnitude/Phase
Measurement (Overlap Display)
