R3765/67G Series Network Analyzer Operation Manual
5.1 Measurement of Transmission Characteristic (2 Trace Display)
5-2
The display on the screen is as follows.
The display contents of input port on upper left of the screen are different depending
on the model.
The display of each type is as follows. (Active channel : CH2)
TRN : TRANSMISSION
The display section of input port (Example S21 : CG type)
Figure 5-1 Auto-scale of the First Trace of Magnitude/Phase
Measurement (Overlap Display)
AG type BG type CG type
B/R TRN S21
