ADVANTEST R3765G Series

R3765/67G Series Network Analyzer Operation Manual
2.1 Front Panel Descriptions
2-1
2 PANEL DESCRIPTION
The names and the functions of each part on the front and rear panel side and the display screen
are described.
2.1 Front Panel Descriptions
2.1.1 R3765AG/67AG
Figure 2-1 Front-Panel Descriptions (R3765AG/67AG)
1
4
5
9
8
7
6
10
12
11
14 13
3
2
