R3765/67G Series Network Analyzer Operation Manual
7.15 Hard Copy
7-153
7.15.2 Selecting Plot Data
Selects items to be hard-copied.
Since the items to be set in this menu are independent to the channels, they are set to the active
channel only.
The setting and the explanation
Press the [COPY] to call the copy menu. (Refer to section A.4.)
Press the {DEFINE PLOT} to call the plot data menu.
Plot data menu
{PLOT DATA ON/OFF} : Sets ON/OFF of the measurement data output.
{PLOT MEMORY ON/OFF} : Sets ON/OFF of the memory data output.
{PLOT GRATICULE ON/OFF}: Sets ON/OFF of the coordinate output.
{PLOT TEXT ON/OFF} : Sets ON/OFF of the text data output.
{PLOT MARKER ON/OFF} : Sets ON/OFF of the marker data output.
{PLOT REF LINE ON/OFF} : Sets ON/OFF of the reference line output.
Note: When both the text data output and the marker data output are set to ON, the
output of the marker list and filter analysis result is also set.
7.15.3 Specifying Pen
Selects the pen number and line type to be used.
The setting and the explanation
Press the [COPY] to call the copy menu. (Refer to section A.4.)
Press the {CONFIGURE PLOT} to call the plotter pen menu.
Plotter pen menu
{PEN NUM DATA} : Specifies the pen number of the measurement data.
{PEN NUM MEMORY} : Specifies the pen number of the memory data.
{PEN NUM GRATICULE} : Specifies the pen number of the coordinate data.
{PEN NUM TEXT} : Specifies the pen number of the text data.
{PEN NUM MARKER} : Specifies the pen number of the marker data.
{LINE TYPE DATA} : Selects the line type of the measurement data.
{LINE TYPE MEMORY} : Selects the line type of the memory data.
• The selection of the line type is as follows.
0 ; Solid line
1 ; Dotted line
2 ; Dashed line
3 ; Chain line
1
2
3
1
2
3
