R3765/67G Series Network Analyzer Operation Manual
3.5 Measurement Samples of Simple Transmission Characteristics
3-12
3.5.3 Magnitude measurement
Adjust the scale to see the display trace easily.
[SCALE] {AUTO SCALE}
The display on the screen is as follows.
Figure 3-10 Auto-scale of Magnitude Measurement
1
To Next Page
