R3765/67G Series Network Analyzer Operation Manual

3.5 Measurement Samples of Simple Transmission Characteristics

3-18

Adjust the scale to see the display trace easily.

Pressing [SCALE] {AUTO SCALE} shows the following display on the screen.

Figure 3-15 Auto-scale of Group Delay Measurement
