R3765/67G Series Network Analyzer Operation Manual

7.9 Sweep

7-96

Here is an example how the program sweep is applied to the trace on the screen.

Figure 7-9 The Screen before the Segment Edited

Each segment is edited as shown like the above-mentioned.

SEG. START STOP POWER IF RBW POINT

80MHz

860MHz

900MHz

860MHz

900MHz

1680MHz

10.0dBm

5.0dBm

10.0dBm

1kHz

10kHz
