R3765/67G Series Network Analyzer Operation Manual
10.1 Preparing for a Performance Test
10-3
Table 10-1 Required Measurement Instrument for Performance Test (3 of 3)
10.1.3 General Note
• Use an AC power source having a voltage of 90V to 250V and a frequency of 48Hz to 66Hz.
• When connecting the power supply cable, turn OFF the POWER switch.
• The R3765/67G series must be tested under the following conditions:
Temperature : +23°C to ±5°C
Relative humidity : 80% RH or less
Free from dust, vibration and noise.
Test items Measurement Instrument Remarks
Dynamic
accuracy
• Step attenuator
Variable range:0 dB to 90 dB
Accuracy : Within 0.02 dB
HP8496B
(Calibrated under the
national standard)
Refer to
section 10.9
• RF cables
(SMA(m)/SMA(m) 50Ω) × 2
A01253-060
• Conversion connectors
(N(m)/SMA(f)) × 2
HRM-554S
• 3dB fixed attenuators
(SMA(f)/SMA(m)) × 2
AT-103
• 50Ω to 75Ω conversion adapter
(when OPT 12 or 13 is installed)
(75ΩN(m)/50ΩN(f)) × 2
11852B
(Agilent Technolo-
gies)
Attenuation
accuracy
(OPT10)
• RF cable
(SMA(m)/SMA(m) 50Ω)
A01253-060
• Conversion connectors
(N(m)/SMA(f)) × 2
HRN-554S
• RF cable (For OPT12 or 13)
(N(m)/N(m) 75Ω)
8120-6468
(Agilent Technolo-
gies)
