R3765/67G Series Network Analyzer Operation Manual
7.13 GPIB Block
7-138
7.13 GPIB Block
The GPIB block is used to set the controller function, GPIB bus and GPIB address. For procedure
how to create a program, refer to the “programming manual” of the separate volume.
PROGRAM
[RUN] : Call the BASIC controller menu. (Refer to sub-section 7.13.1.)
REMOTE
[LCL] : Calls the GPIB menu. (Refer to sub-section 7.13.2.)
Moreover, when the R3765/67G series is in the remote state by GPIB, it return
back to the local state by pressing the key.
Note: The operation key of all the panel key becomes disable in the remote state
except this key.
GP-IB
PROGRAM
RUN
REMOTE
LCL
To Next Page
