R3765/67G Series Network Analyzer Operation Manual
7.3 STIMULUS Block
7-8
7.3.2 Interlocking between Channels
Selects whether the measurement condition concerning the signal source is set at the same con-
dition or independently set in each channel when two-channel simultaneous measurement.
(1) For interlock setting :
The conditions which has been set to the active channel will be automatically set to the oth-
er channel as same.
(2) For independent setting :
Different measuring condition can be set to channel 1 and 2, respectively.
The setting conditions which can be interlocked between channels are show below:
• Sweep type
• Frequency
• Output level
• Sweep time
• Number of measurement point
• Resolution bandwidth
The Setting and the Explanation
Press the [MENU] to call the signal source menu. (Refer to section A.4.)
Press the {COUPLED CH ON/OFF} to select whether the setting conditions concern-
ing two measurements are set to the same or not.
ON : Measures channel 1 and channel 2 simultaneously.
OFF : Measures channel 1 and channel 2 alternately. (Performs the measurement
of channel 1 and them channel 2.)
• When the sub-measure screen (channel 3 or channel 4) of channel 1 or channel 2
is selected, channel 3 always operates with channel 1 and channel 4 operates
with channel 2.
On the display of the sub-measure screen, the input port can be set in the state of
sub-measure ON.
However, INPUT PORTs can be set independently.
