R3765/67G Series Network Analyzer Operation Manual
7.3 STIMULUS Block
7-7
{ATTENUATOR SOURCE} : Sets an attenuator value for the signal source (used with
only AG model).
*OPT 10 (Output attenuator)
{ATTENUATOR PORT 1} : Sets the PORT 1 attenuator value.
*OPT10 (Output attenuator)
{ATTENUATOR PORT 2} : Sets the PORT 2 attenuator value. (used with the CG
model)
*OPT10 (Output attenuator)
{ATTENUATOR PORT3} Sets the PORT3 attenuator value. (used with only
OPT11 or 13)
* OPT10 (output attenuator)
{ATTENUATOR PORT4} Sets the PORT4 attenuator value. (used with only
OPT14)
* OPT10 (output attenuator)
Trigger menu
{CONTINUOUS} : Continuously performs sweep.
{SINGLE} : Performs sweep once.
If this key is pressed in the middle of a sweep, the
measurement of the sweep is interrupted and a sweep
is restarted.
{HOLD} : Stops sweep measurement.
If this key is pressed in the middle of sweep, immediately
sweep is interrupted.
{INT TRIG} : Automatically starts sweep by an internal source.
{EXT TRIG} : Starts sweep by an external synchronization signal.
The external synchronization signal is input through the
parallel I/O connector 18-pin of the rear panel.
(Negative logic, pulse width ; 1µs or more.)
{TRIGGER DELAY} : Sets delay time between receiving the trigger signal and
the start of sweep.
