R3765/67G Series Network Analyzer Operation Manual
4.1 Basic Keys Operations
4-1
4 BASICS OPERATION
This chapter describes about the keys and the soft menus of the R3765/67G series basically.
4.1 Basic Keys Operations
Front panel keys are grouped under the following six function blocks. The operation is performed
by the combination of these blocks.
(1) ACTIVE CHANNEL block
The R3765/67G series has 2 measurement channels. (Refer to section 7.1.)
Select an active channel which can be set and changed.
(2) ENTRY block
Input numeric value to the selected function. (Refer to section 7.2.)
(3) STIMULUS block
Make the setting for the signal resource. (Refer to section 7.3.)
(4) RESPONSE block
Make setting of the receiver part and the information on the display screen. (Refer to
section 7.4.)
(5) INSTRUMENT STATE block
Make the system setting such as save/recall or hard copy, etc. (Refer to section 7.11.)
(6) GPIB block
Make the setting of controller function and GPIB. (Refer to section 7.13.)
4.2 Basic Key Operation Examples
The key operation of the R3765/67G series is performed in the following three ways.
(1) The case that the numeric value data input is required.
[Panel key] {Soft key} [Panel key] in ENTRY block
[Panel key] [Panel key] in ENTRY block
(2) The case that the selection is made only by soft key menu.
[Panel key] {Soft key}
Pressing a key for more than about 0.5 seconds can input the key continuously.
