R3765/67G Series Network Analyzer Operation Manual
7.4 RESPONSE Block
7-23
7.4.6 Trace Data Selection
The trace data selection menu allows you to select the measured data, the memory data or both
data.
The Setting and Explanation
Press the [DISPLAY] to call the display menu. (Refer to section A.4.)
Press the {DISPLAY[ ]} to call the trace data selection menu.
Trace data selection menu
{DISPLAY DATA} : Displays the measured data only.
{DISPLAY MEMORY} : Displays the memory data only.
{DISPLAY DATA & MEM} : Displays both the measured data and the memory data.
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: ON
SPLIT CH: ON
CH1 SUB MEAS:
ON
CH2 SUB MEAS:
ON
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: OFF
SPLIT CH: ON
CH1 SUB MEAS:
ON
CH2 SUB MEAS:
ON
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: ON CH2
CH1 CH4
SPLIT CH: ON
CH1 SUB MEAS:
OFF
CH2 SUB MEAS:
ON
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: OFF
SPLIT CH: ON
CH1 SUB MEAS:
OFF
CH2 SUB MEAS:
ON
marker list
marker list
marker list
marker list
CH1
CH3
CH1
CH1
CH3
CH2
CH4
1
2
3
