R3765/67G Series Network Analyzer Operation Manual
7.7 Time Domain Function(OPT 70)
7-88
7.7.4 Time Domain Transformation Mode
Sets the transformation mode to the time domain.
Procedure
Press [FUNCTION] to call the function menu.
Press {TRANSFORM} to call the time domain transformation menu.
Press {TRANSFORM MODE} to call the time domain transformation mode menu.
The time domain transformation mode menu
The mode is independently set for each channel.
{SET FREQ LOW PASS} : Sets a frequency range which conforms to the low pass
mode restrictions.
{LOW PASS IMPULSE} : Selects the low pass impulse transformation mode.
{LOW PASS STEP} : Selects the low pass step transformation mode.
{BANDPASS} : Selects the bandpass transformation mode.
7.7.5 Transformation of the Time Domain Horizontal Axis
Sets the annotation of the horizontal axis to a time or distance display.
Procedure
Press [FUNCTION] to call the function menu.
Press {TRANSFORM} to call the time domain transformation menu.
Press {TRANSFORM STIMULUS} to call the time domain stimulus menu.
The time domain stimulus menu
The mode is independently set for each channel.
{TIME} : Sets the annotation of the horizontal axis to time (sec).
{DISTANCE} : Sets the annotation of the horizontal axis to distance
(m).
{REFLECTION TIME} : Sets the annotation of the horizontal axis to time (sec)
and displays half of the {TIME} value when measuring
the reflection time.
{REFLECTION DISTANCE}: Sets the annotation of the horizontal axis to distance (m)
and displays half of the {DISTANCE} value.
{VELOCITY FACTOR} : Sets the velocity factor.
