R3765/67G Series Network Analyzer Operation Manual
10.1 Preparing for a Performance Test
10-2
Table 10-1 Required Measurement Instrument for Performance Test (2 of 3)
Test items Measurement Instrument Remarks
Output level
linearity
• Power meter
Frequency : 300kHz to 3.8GHz
(R3765G Series)
300kHz to 8GHz
(R3767G Series)
Power range: -21dBm to +17dBm
NRVS (R&S)
(Calibrated under the
national standard)
Refer to
section 10.4
• Power sensor
Frequency : 300kHz to 3.8GHz
(R3767G Series)
300kHz to 8GHz
(R3767G Series)
Power range: -21dBm to +17dBm
NRV - Z51 (R&S)
(DC to 18GHz)
• 50Ω to 75Ω conversion adapter
(when OPT 12 or 13 is installed)
11852 B
(Agilent Technologies)
Directivity • Calibration kit Model 9617A3
(DC to 18GHz, N type
connector)
Model 9617M3
(For OPT 12 or 13)
(DC to 3.8GHz, N75Ω)
Refer to
section 10.5
Test port load
match
• Calibration kit
• Directivity bridge
Model 9617A3
(DC to 18GHz, N type
connector)
ZRB2VAR-52
(5MHz to 3GHz)
Model 9617M3
(For OPT 12 or 13)
(DC to 3.8GHz, N75Ω)
Refer to
section 10.6
Crosstalk • Calibration kit Model 9617A3
(DC to 18GHz, N type
connector)
Model 9617M3
(For OPT 12 or 13)
(DC to 3.8GHz, N75Ω)
Refer to
section 10.8
