R3765/67G Series Network Analyzer Operation Manual
A.2 Measuring Time
A-3
A.2 Measuring Time
The measurement time is the time to acquire the data plus the frequency setup time.
Data acquiring time is set up as SWEEP TIME.
Frequency setup time is different depending on the frequency setup.
The following shows the typical values.
(Example)
Start frequency 1GHz
Stop frequency 2GHz
Measuring point number 101 points
Frequency between measuring points: 10MHz → Setup time, 50µsec/point
Total setup time is (50µsec/point) × 100 points = 5msec.
• When the frequency between the measuring points is more than 5MHz, the setup
time is 50µsec per about 5MHz.
Band switching time: About 5msec
• The R3765/67G series is composed by the following frequency bands.
Each time the band is switched, the setup time is about 5msec.
The setup time is the total of and , that is 18msec. Therefore, the measurement
time is SWEEP TIME plus 18msec.
Band Frequency range
1 300kHz to 3MHz
2 3MHz to 15MHz
3 15MHz to 20MHz
4 20MHz to 40MHz
5 40MHz to 80MHz
6 80MHz to 160MHz
7 160MHz to 320MHz
8 320MHz to 560MHz
9 560MHz to 1120MHz
10 1120MHz to 2160MHz
11 2160MHz to 3800MHz
12 3800MHz to 6000MHz
13 6000MHz to 8000MHz
1
2
3 1 2
To Next Page
