R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-12
(6) Connection to External Devices
(7) General Specification
Signal for external display 15 pins, D-SUB connector (VGA)
GPIB IEEE488.1, IEEE488.2 applicable
Parallel port TLL level
Output port (8 bits × 2 ports)
Input/Output port (4 bits × 2 ports)
Serial port Serial I/O port for the accessories
Printer port Compliant with IEEE-1284-1994
LAN port (Option) 10Base-T
Keyboard Based on IBM PC-AT
External reference frequency
input
1MHz, 2MHz, 5MHz, 10MHz (±10ppm)
More than 0dBm (50Ω)
Probe power ±12V ±0.5V, 300mA
Operating environment
When FDD used. Temperature range +5 to +40°C
Relative humidity under 80% (non-condensing)
When FDD unused. Temperature range 0 to +50°C
Relative humidity under 80% (non-condensing)
Storing environment -20 to +60°C
Power source AC100V to 120V, 50Hz/60Hz
AC220V to 240V, 50Hz/60Hz
(Auto-switch between 100VAC and 200VAC type)
Outer dimensions About 424mm (width) × 220mm (height) × 400mm (depth)
Mass 18.5kg or less
Power draw 250VA or less
