R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-11
(5) Other Functions
Display Section
Displaying device 8.4 inch TFT color liquid crystal display
Back light Intensity half-value period: 40,000 hours (Typical value)
Error compensation Normalization, Normalization & Isolation, and 1-port calibration
2 ports calibration (R3765CG/67CG only)
3 ports calibration (For OPT 11 and OPT 13 only)
4 ports calibration (OPT14 only)
Averaging and smoothing
Electrical length correction, Phase offset correction
Marker function Independent 10 markers can be set to each channel.
∆Marker function, Search function, Marker → function
Limit line function Up to 31 segments can be set.
Pass/Fail display and beep sound functions
Save/Call function Register format: Up to 20 registers are used to save data.
File format: Saved to a floppy disk or the internal memory (8
MB).
Controller function BASIC programming function (Program size: 2MB)
FDD function Compliant with MS-DOS FAT format in three modes (DD 720 KB,
HD 1.2 MB or 1.4 MB)
