ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-10
Crosstalk 90dB (300kHz to 40MHz)
100dB (40MHz to 2.6GHz)
90dB (2.6GHz to 3.8GHz)
80dB (3.8GHz to 5.0GHz)
70dB (5.0GHz to 8.0GHz)
For OPT 12 or 13
80dB (300kHz to 40MHz)
85dB (40MHz to 2.0GHz)
80dB (2.0GHz to 3.8GHz)
For OPT 14
90dB (300kHz to 40MHz)
95dB (40MHz to 2.6GHz)
85dB (2.6GHz to 3.8GHz)
75dB (3.8GHz to 5.0GHz)
65dB (5.0GHz to 8.0GHz)
Maximum input level 0dBm (R3765AG/67AG)
+6dBm (R3765BG/67BG)
+12dBm (R3765CG/67CG) (+20 dBm for OPT 12 or OPT 13)
Noise level At the allowable input level
3kHz bandwidth -85dB (300kHz to 40MHz)
-90dB (40MHz to 3.8GHz)
-80dB (3.8GHz to 8.0GHz)
300Hz bandwidth -95dB (300kHz to 40MHz)
-100dB (40MHz to 3.8GHz)
-90dB (3.8GHz to 8.0GHz)
Maximum port-biased R3765CG/67CG only (For the CG model only, excluding CG
model analyzers with OPT 11, 13 or 14 installed)
±30V
dc
, 0.5A
Input head damage level +21dBm, 30V
dc
Tester port connector N type (f) (75Ω dBm for OPT 12 or OPT 13)
(Continued)

ADVANTEST R3765G Series Specifications

General

Brand	ADVANTEST
Model	R3765G Series
Category	Measuring Instruments
Language	English
