R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-9
(4) Test Port Characteristic
Load match 16dB (300kHz to 40MHz, 23°C ± 5°C)
18dB (40MHz to 2.6GHz, 23°C ± 5°C)
16dB (2.6GHz to 3.8GHz, 23°C ± 5°C)
14dB (3.8GHz to 8.0GHz, 23°C ± 5°C)
For OPT 12 or 13
16dB (300kHz to 2GHz, 23°C ± 5°C)
15dB (2GHz to 3.8GHz, 23°C ± 5°C)
Source match R3765BG/CG, R3767BG/CG only
14dB (300kHz to 40MHz, 23°C ± 5°C) *
16dB (40MHz to 2.6GHz, 23°C ± 5°C) *
15dB (2.6GHz to 3.8GHz, 23°C ± 5°C) *
12dB (3.8GHz to 8.0GHz, 23°C ± 5°C) *
For OPT 12 or 13
14dB (300kHz to 40MHz, 23°C ± 5°C) *
16dB (40MHz to 2GHz, 23°C ± 5°C) *
15dB (2GHz to 3.8GHz, 23°C ± 5°C) *
* : For OPT 10, Attenuation = 0dB
Source match
(Attenuation=20/40/60dB)
R3765BG/CG+OPT 10, R3765BG/CG+OPT 10+OPT 11/14
R3767BG/CG+OPT 10, R3767BG/CG+OPT 10+OPT 11/14
13dB (300kHz to 40MHz, 23°C ±5°C)
16dB (40MHz to 2.6GHz, 23°C ±5°C)
15dB (2.6GHz to 3.8GHz, 23°C ±5°C)
12dB (3.8GHz to 8.0GHz, 23°C ±5°C)
R3765BG/CG+OPT 10+OPT 12/13
13dB (300kHz to 40MHz, 23°C ±5°C)
16dB (40MHz to 2GHz, 23°C ±5°C)
15dB (2GHz to 3.8GHz, 23°C ±5°C)
Directivity R3765BG/CG, R3767BG/CG only
28dB (300kHz to 40MHz, 23°C ± 5°C)
30dB (40MHz to 2.6GHz, 23°C ± 5°C)
26dB (2.6GHz to 3.8GHz, 23°C ± 5°C)
22dB (3.8GHz to 8.0GHz, 23°C ± 5°C)
For OPT 12 or 13
28dB (300kHz to 40MHz, 23°C ± 5°C)
27dB (40MHz to 2GHz, 23°C ± 5°C)
22dB (2GHz to 3.8GHz, 23°C ± 5°C)
