ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
7.4 RESPONSE Block
7-27
• Color menu (3 of 3)
{ANNOTATION} : Sets the color of the channel name being displayed on the
box of the trace display window and the color of the
annotation such as stimulus data.
When this function is selected, the RGB menu is displayed.
{CLOCK} : Sets the color of the date and clock display at the top right-
hand corner of the screen.
When this function is selected, the RGB menu is displayed.
{LABEL} : Sets the color of the label display.
When this function is selected, the RGB menu is displayed.
{OVERLAY TEXT} : Sets the color of the overlay text displayed in the active
area.
When this function is selected, the RGB menu is displayed.
{BASIC TEXT} : Sets the color of the BASIC TEXT.
When this function is selected, the RGB menu is displayed.
RGB menu
Determines the color of each item by the proportions of R(Red), G(Green) and
B(Blue). Each value of RGB can be set in the range 0 to 255.
A setting of 0 for each value is displayed as black while a setting of 255 for each value
is displayed as white.
{RED} : Performs the setting of RED.
{GREEN} : Performs the setting of GREEN.
{BLUE} : Performs the setting of BLUE.
The changed value is stored in the environmental file of the system.
It is valid in turning on the power next time.
