R3765/67G Series Network Analyzer Operation Manual
7.5 Calibration
7-41
In case the isolation omitted.
Press {OMIT ISOLATION} and then {DONE ISOLATION}.
Isolation calibration
(a) Connect the load standard to port 1 and port 2.
(b) Press {FMD ISOL’N}.
The message “Wait for Sweep .” is displayed and the calibration data is obtained.
The calibration is completed when the message disappears.
(c) Press {REV ISOL’N}.
The message “Wait for Sweep .” is displayed and the calibration data is obtained.
The calibration is completed when the message disappears.
Press {DONE ISOLATION}.
Executes the isolation calibration and returns to the 2-port full calibration menu.
CAUTION !
The calibration data of each calibration standard can be acquired again before
{DONE
ISOLATION}
pressed.
Press {DONE 2-PORT}.
Executes 2-port full calibration.
23
24
25
