R3765/67G Series Network Analyzer Operation Manual
7.5 Calibration
7-54
(3) Operation and description (3-port calibration of PORT1, PORT2 and PORT3)
Press [CAL] to call the calibration menu (1/2).
Press {CAL MENU} to call the full calibration selection menu.
<For OPT11/13>
When {3 PORT FULL CAL} is pressed, the 3-port calibration is selected, then the 3-
port full calibration menu is displayed.
<For OPT14>
Press {3PORT CAL MENU} to display the 3 port cal menu.
When {P1-P2-P3 FULL CAL} is pressed, the 3-port calibration of PORT1, PORT2 and
PORT3 is selected, then the 3-port full calibration menu is displayed.
Notes:
1. After calibration has been performed, turn the calibration off, clear the previous
calibration data and start the 3-port full calibration. If calibration is being executed
or calibration data exists, calibration operation is disabled to prevent erroneous
operation from occurring and causing the calibration data to be deleted. (Refer to
Section 7.5.10.)
2. If the sweep conditions are changed before {DONE 3-PORT} is pressed, a message
"Calibration canceled !" is displayed and the calibration data is cleared.
Press {PORT1 REFLECT’N} to call the PORT1 reflection menu.
Connect the open standard to TEST PORT1, then press {S11 (PORT1) OPEN}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the short standard to TEST PORT1, then press {S11 (PORT1) SHORT}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the load standard to TEST PORT1, then press {S11 (PORT1) LOAD}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Press {DONE PORT1 REFLECT’N} to execute the reflection calibration for TEST
PORT1.
When the reflection calibration for TEST PORT1 has been completed, the 3-port full
calibration menu is resumed.
Press {PORT2 REFLECT’N} to call the PORT2 reflection menu.
Connect the open standard to TEST PORT2, then press {S22 (PORT2) OPEN}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
