R3765/67G Series Network Analyzer Operation Manual
7.8 CDMA IF Filter Analysis Function
7-91
measurement is set to OFF).
{ATTN FREQ2} : Specifies the second frequency for the guaranteed
attenuation measurement. The guaranteed
attenuation is not measured when this frequency is
set to 0 (zero) (as the guaranteed attenuation
measurement is set to OFF).
Phase linearity analysis menu
{PHASE LINEARITY ON/OFF}: Turns the Phase linearity analysis ON or OFF.
Note: The phase linearity analysis cannot be performed at the same time as the CDMA
phase linearity analysis.
{PARTIAL ON/OFF} : Turns the partial definition analysis ON or OFF.
When this function is set to ON, the phase linearity is
analyzed for the section specified by the {SET
RANGE} (which is in the partial menu under the
marker search menu). When set to OFF, the phase
linearity is analyzed for the full measurement range.
