R3765/67G Series Network Analyzer Operation Manual
7.14 Save/Recall
7-150
• Recall menu (4 of 4)
{RECALL REG-16} : Recalls the setting data, calibration data and memory trace
data saved in the register 16.
{RECALL REG-17} : Recalls the setting data, calibration data and memory trace
data saved in the register 17.
{RECALL REG-18} : Recalls the setting data, calibration data and memory trace
data saved in the register 18.
{RECALL REG-19} : Recalls the setting data, calibration data and memory trace
data saved in the register 19.
{RECALL REG-20} : Recalls the setting data, calibration data and memory trace
data saved in the register 20.
{RECALL POWER OFF}
: The settings are stored automatically when the power is
turned off. When the power is turned on again, the data is
set to the initial state. By pressing this key, the stored data
is read again.
{LOAD FILE} : Calls the load file menu used to load the all informations
stored in the file. (See step or Figure 7-18.)
Load file menu
{LOAD} : Loads all informations stored in the file.
{CURSOR↑} :
{CURSOR↓} :
Note: The file of the cursor position can be recalled.
{Return} : Makes the control return to the recall menu.
Note: If a file stored with RAW ARRAY or DATA ARRAY ON is loaded, the sweep
becames HOLD without reservation.
3
3
Shifts the cursor up/down of file list.
