R3765/67G Series Network Analyzer Operation Manual
10.6 Load Match of Test Port
10-20
• The procedure shown below only applies to OPT14.
Change the RF cable end from TEST PORT3 to TEST PORT4
Read the load match of TEST PORT 4 from trace data with the marker.
<Check> : TEST PORT 4 load match (in 23°C ± 5°C)
300kHz to 40MHz : -16dB or less
40MHz to 2.6GHz : -18dB or less
2.6GHz to 3.8GHz : -16dB or less
3.8GHz to 8.0GHz : -14dB or less (R3767CG OPT14 only)
6
7
8
