R3765/67G Series Network Analyzer Operation Manual
A.4 Soft Key Menu List
A-18
(3)
{S11(PORT1) FWD:OPEN
{S11(PORT1) FWD:SHORT}
{S11(PORT1) FWD:LOAD}
{S22(PORT2) REV:OPEN
{S22(PORT2) SHORT}
{S22(PORT2) LOAD}
{DONE REFLECT’N}
For the path between PORT1 to PORT2
{S11(PORT1) FWD:OPEN
{S11(PORT1) FWD:SHORT}
{S11(PORT1) FWD:LOAD}
{S33(PORT3) REV:OPEN
{S33PORT3) REV:SHORT}
{S33(PORT3) REV:LOAD}
{DONE REFLECT’N}
For the path between PORT1 to PORT3
{S11(PORT1) FWD:OPEN
{S11(PORT1) FWD:SHORT}
{S11(PORT1) FWD:LOAD}
{S44(PORT4) REV:OPEN
{S44(PORT4) REV:SHORT}
{S44(PORT4) REV: LOAD}
{DONE REFLECT’N}
For the path between PORT1 to PORT4
{S22(PORT2) FWD:OPEN
{S22(PORT2) FWD:SHORT}
{S22(PORT2) FWD:LOAD}
{S33(PORT3) REV:OPEN
{S33(PORT3) REV:SHORT}
{S33(PORT3) REV:LOAD}
{DONE REFLECT’N}
For the path between PORT2 to PORT3
{S22(PORT2) FWD:OPEN
{S22(PORT2) FWD:SHORT}
{S22(PORT2) FWD:LOAD}
{S44(PORT4) REV:OPEN
{S44(PORT4) REV:SHORT}
{S44(PORT4) REV:LOAD}
{DONE REFLECT’N}
For the path between PORT2 to PORT4
{S11(PORT1) OPEN
{S11(PORT1) SHORT}
{S11(PORT1) LOAD}
{DONE PORT1 REFLECT’N}
{S22(PORT2) OPEN
{S22(PORT2) SHORT}
{S22(PORT2) LOAD}
{DONE PORT2 REFLECT’N}
{S33(PORT3) OPEN
{S33(PORT3) SHORT}
{S33(PORT3) LOAD}
{DONE PORT3 REFLECT’N}
{S44(PORT4) OPEN
{S44(PORT4) SHORT}
{S44(PORT4) LOAD}
{DONE PORT4 REFLECT’N}
{PORT1 REFLECT’N}
{PORT2 REFLECT’N}
{PORT4 REFLECT’N}
{TRANS P1-P2-P4}
{ISOLATION P1-P2-P4}
{DONE 3-PORT}
{PORT1 REFLECT’N}
{PORT2 REFLECT’N}
{PORT3 REFLECT’N}
{TRANS P1-P2-P3}
{ISOLATION P1-P2-P3}
{DONE 3-PORT}
{P1-P2 ISOLATION}
{P1-P3 ISOLATION}
{P2-P3 ISOLATION}
{OMIT ISOLATION}
{DONE ISOLATION}
{P1-P2 THRU}
{P1-P3 THRU}
{P2-P3 THRU}
{DONE TRANS}
{P1-P2 THRU}
{P1-P4 THRU}
{P2-P4 THRU}
{DONE TRANS}
{P1-P2 ISOLATION}
{P1-P4 ISOLATION}
{P2-P4 ISOLATION}
{OMIT ISOLATION}
{DONE ISOLATION}
(4)
(5)
