PPC405 Processor
dcbtst
Data Cache Block Touch for Store
Preliminary User’s Manual
dcbtst
Data Cache Block Touch for Store
EA ← (RA|0) + (RB)
DCBTST(EA)
An effective address (EA) is formed by adding an index to a base address. The index is the contents of register RB.
The base address is 0 if the RA field is 0 and is the contents of register RA otherwise.
If the data block at the EA is not in the data cache and the EA address is marked as cacheable, the data block is
loaded into the data cache.
If the EA is marked as non cacheable, or if the data block at the EA is in the data cache, no operation is performed.
This instruction is not allowed to cause data storage exceptions or data TLB miss exceptions. If execution of the
instruction would cause such an exception, then no operation is performed, and no exception occurs.
If instruction bit 31 contains 1, the contents of CR[CR0] are undefined.
Registers Altered
•None
Invalid Instruction Forms
• Reserved fields
Programming Notes
The dcbtst instruction allows a program to begin a cache block fetch from main storage before the program needs
the data. The program can later store data from GPRs into the cache block, without incurring the latency of a cache
miss.
Architecturally, dcbtst brings data into the cache in “Exclusive” mode, which allows the program to alter the
cached data. “Exclusive” mode is part of the MESI protocol for multi-processor systems, and is not implemented.
The implementation of the dcbtst instruction is identical to the implementation of the dcbt instruction.
Exceptions
This instruction is considered a “load” with respect to data storage exceptions. See Data Storage Interrupt on
page 120.
This instruction is considered a “load” with respect to data address compare (DAC) debug exceptions. See Debug
Interrupt on page 128.
Architecture Note
This instruction is part of the PowerPC Embedded Virtual Environment.
dcbtst RA, RB
31
RA RB 246
0 6 11 16 21 31
