Pro Tools Reference Guide40
For 192 I/Os equipped with the optional
Digital I/O Card, the additional AES/EBU I/O
ports on the optional card are listed as AES/EBU
9–10, AES/EBU 11–12, AES/EBU 13–14, and
AES/EBU 15–16.
10 Click other tabs (such as Analog In and Ana-
log Out) for additional configuration options
specific to the audio interface. These include:
• On the 96 I/O, configuring the operating
levels of analog inputs and outputs (+4 dBu
or –10 dBV).
• On the 96i I/O, configuring the operating
levels of analog inputs and outputs (+4 dBu
or –10 dBV).
• On the 192 I/O analog input, setting the
input connector and Soft Limit
• On the 192 I/O, configuring the two sets of
trims for analog inputs and outputs.
• On the 192 I/O and 192 Digital I/O, config-
uring real-time Sample Rate Conversion for
digital inputs.
• On the 192 I/O and 192 I/O Digital, config-
uring inputs and outputs on any optional
A/D card, D/A card, or Digital I/O cards in-
stalled in the unit.
11 Repeat the above steps for each additional
Pro Tools|HD audio interface.
12 Repeat the above steps for any Legacy I/Os
connected to the Pro Tools|HD audio interfaces
in your system. Before you can configure a Leg-
acy I/O, it must first be initialized in Hardware
Setup.
13 Click OK.
Initializing MIX-Series Legacy
Peripherals (on a Pro Tools|HD System)
Before you can configure a Legacy I/O, it must
first be initialized in Hardware Setup.
To initialize a Legacy I/O on a Pro Tools|HD
system:
1 Start up your Pro Tools system. See “Starting
Up or Shutting Down Your System” on page 31.
2 Make sure to lower the volume of your output
devices. Very loud digital noise may be emitted
before the Legacy I/O is initialized.
3 Turn on your Legacy I/O.
4 From the Peripherals list, choose the primary
audio interface (the Pro Tools|HD interface to
which your Legacy I/O is connected).
5 In the Main page of the Hardware Setup dia-
log, select the Legacy I/O option under Port Set-
tings.
6 In the Peripherals list, “No Interface” is listed
twice, directly below the primary audio inter-
face. Click the first “No Interface.” An Interface
pop-up menu appears in the Hardware Setup di-
alog, listing supported I/O choices.
7 From the Interface pop-up menu, select the
type of Legacy I/O you connected.
The Main page updates with controls that can
be configured.
8 Repeat the above steps for each additional
Legacy I/O.
For more information on Hardware Setup
controls for each Pro Tools|HD audio inter-
face, refer to the Pro Tools|HD Getting
Started Guide or the guide for that audio in-
terface.
Use the Up and Down Arrow keys to scroll
though peripherals in the Peripherals list.
For information on Hardware Setup controls
for each Legacy audio interface, refer to the
guide for that interface.
