186 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
1
Disable inverter
Trigger bit = 0-1 edge: The inverter is disabled.
Trigger bit = 0: The inverter is enabled (unless there is another cause for
inverter disable).
Notes:
In all device states, a 0-1 edge causes an immediate change to the
inhibited state with one exception: If the inverter is in the error status
and the error condition still exists, the inverter remains in the error
status.
Changing to the disabled state causes an immediate stop of the
motor, regardless of the stop method set in 0x2838:003 (P203.03).
The motor coasts down as a function of the mass inertia of the
machine.
In the disabled state, the motor cannot be started.
After the inverter disable is deactivated, a renewed start command is
required to restart the motor.
The cause(s) that are active for the disabled state are shown in
0x282A:001 (P126.01).
2
Stopping
Trigger bit = 1: Motor is stopped.
Trigger bit = 0: No action / Deactivate stop again.
Notes:
The stop method can be selected in 0x2838:003 (P203.03).
3
Activate quick stop
Trigger bit = 1: "Quick stop" function activated.
Trigger bit = 0: no action / deactivate function again.
Notes:
The "Quick stop" function brings the motor to a standstill within the
deceleration time set in 0x291C (P225.00).
The "Quick stop" function has a higher priority than the "Run"
func
tion.
4
Reset error
Trigger bit = 0-1 edge: Active error is reset (acknowledged) if the error
condition is not active anymore and the error is resettable.
Trigger bit = 0: No action.
Notes:
After resetting the error, a new enable/start command is required to
restart the motor.
Error handling
84
5
Activate DC braking
Trigger bit = 1: "DC braking" function activated.
Trigger bit = 0: no action / deactivate function again.
DC braking
262
8
Run forward (CW)
Trigger bit = 0-1 edge: Motor is started in forward rotating direction
(CW). Trigger bit = 1-0 edge: Motor is stopped again.
Notes:
The stop method can be selected in 0x2838:003 (P203.03).
In the case of a bipolar setpoint selection (e.g ±10 V), the function is
executed irrespective of the rotating direction. The rotating direction
is determined by the sign of the setpoint.
The function also serves to realise an automatic start after switch-on.
Starting performance
97
The "Invert rotation [13]" function can be used in connection with this
function.
9
Run reverse (CCW)
Trigger bit = 0-1 edge: Motor is started in backward rotating direction
(CCW).
Trigger bit = 1-0 edge: Motor is stopped again.
Notes:
The stop method can be selected in 0x2838:003 (P203.03).
In the case of a bipolar setpoint selection (e.g ±10 V), the function is
executed irrespective of the rotating direction. The rotating direction
is determined by the sign of the setpoint.
The function also serves to realise an automatic start after switch-on.
Starting performance
97
The "Invert rotation [13]" function can be used in connection with this
function.
