194 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2631:002
(P400.02)
Function list: Run
(Function list: Run)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Run" function.
Function 1: Start / stop motor (default setting)
Function 1 is active if no further start commands (start forward/start
reverse) have been
connected to triggers, no keypad control is active and
no network control is active.
Trigger = TRUE: Let motor rotate forward (CW).
Trigger = FALSE: Stop motor.
Notes to function 1:
If "Enable inverter" 0x2631:001 (P400.01) is set = "Constant TRUE [1]",
the only permissible trigger for this function is a digital input in order
that the motor can be stopped again any time.
The stop method can be selected in 0x2838:003 (P203.03).
The function also serves to realise an automatic start after switch-on.
 Starting performance  97
Function 2: Start enable/stop motor
Function 2 is active if further start commands have been connected to
triggers, keypad control is active or network control is active.
Trigger = TRUE: Start commands of the active control source are
enabled.
Trigger = FALSE: Stop motor.
Notes to function 2:
If no separate start enable is required for the application, the trigger
"Constant TRUE [1]" must be set.
The stop method can be selected in 0x2838:003 (P203.03).
11
Digital input 1
State of X3/DI1, taking an inversion set in 0x2632:001 (P411.01) into
consideration.
0x2631:003
(P400.03)
Function list: Activate quick stop
(Function list: Quick stop)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate quick stop" function.
Trigger = TRUE: Activate quick stop.
Trigger = FALSE: Deactivate quick stop.
Notes:
The "Quick stop" function brings the motor to a standstill within the
deceleration time set in 0x291C (P225.00).
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:004
(P400.04)
Function list: Reset fault
(Function list: Reset fault)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Reset fault" function.
Trigger = FALSE↗TRUE (edge): Active error is reset (acknowledged) if
the error condition is not active anymore and the error is resettable.
Trigger = FALSE: no action.
12
Digital input 2
State of X3/DI2, taking an inversion set in 0x2632:002 (P411.02) into
consideration.
0x2631:005
(P400.05)
Function list: Activate DC braking
(Function list: DC braking)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate DC braking" function.
Trigger = TRUE: Activate DC braking.
Trigger = FALSE: Deactivate DC braking.
CAUTION!
DC braking remains active as long as the trigger is set to TRUE.
 DC braking

262
0
Not connected
No trigger assigned (trigger is constantly FALSE).
