Parameter
Name / value range / [default setting]
Info
0x2631:010
(P400.10)
Function list: Jog foward (CW)
(Function list: Jog foward)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Jog foward (CW)" function.
Trigger = TRUE: Let motor rotate forward with preset 5.
Trigger = FALSE: Stop motor.
CAUTION!
The jog operation has a higher priority than the "Run" function, all other
start commands and the keypad key
.
If jog operation is active, the motor cannot be stopped with the
previ
ously mentioned functions!
However, jog operation can be interrupted by the "Quick stop"
func
tion.
Notes:
The preset value 5 can be set in 0x2911:005 (P450.05).
The stop method can be selected in 0x2838:003 (P203.03).
If "Jog foward (CW)" and "Jog reverse (CCW)" are activated at the
same
time, the motor is stopped using the stop method and jog operation
must be triggered again.
Jog operation cannot be started automatically. The "Start at power
up"
option in 0x2838:002 (P203.02) does not apply to jog operation.
0 Not connected No trigger assigned (trigger is constantly FALSE).
0x2631:011
(P400.11)
Function list: Jog reverse (CCW)
(Function list: Jog reverse)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Jog reverse (CCW)" function.
Trigger = TRUE: Let motor rotate backward with preset 6.
Trigger = FALSE: Stop motor.
CAUTION!
The jog operation has a higher priority than the "Run" function, all other
start commands and the keypad key
.
If jog operation is active, the motor cannot be stopped with the
previ
ously mentioned functions!
However, jog operation can be interrupted by the "Quick stop"
func
tion.
Notes:
The preset value 6 can be set in 0x2911:006 (P450.06).
The stop method can be selected in 0x2838:003 (P203.03).
If "Jog foward (CW)" and "Jog reverse (CCW)" are activated at the
same
time, the motor is stopped using the stop method and jog operation
must be triggered again.
Jog operation cannot be started automatically. The "Start at power
up"
option in 0x2838:002 (P203.02) does not apply to jog operation.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:012
(P400.12)
Function list: Activate keypad control
(Function list: Keypad control)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate keypad control" function.
Trigger = TRUE: activate keypad as control source.
Trigger = FALSE: no action / deactivate keypad as control source again.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:017
(P400.17)
Function list: Activate network setpoint
(Function list: Setp: Network)
From version 02.01
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate network setpoint" function.
Trigger = TRUE: the network is used as setpoint source (if the trigger
assigned has the highest setpoint priority).
Trigger = FALSE: no action / deactivate function again.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
116 Network setpoint active (from version 02.00) TRUE if a change-over to network setpoint is requested via bit 6 of the
AC drive control word0x400B:001 (P592.01). Otherwise FALSE.
Notes:
Set this selection if the network setpoint is to be activated via bit 6 of
the AC drive control word.
The AC drive control word can be used with any communication
pro
tocol.
 AC Drive Profile

