Parameter
Name / value range / [default setting]
Info
0x2631:037
(P400.37)
Function list: Activate network control
(Function list: Network control)
For further possible settings, see parameter
0x2631:001 (P400.01).

364
Assignment of a trigger for the "Activate network control" function.
Trigger = TRUE: Activate network control.
Trigger = FALSE: No action / deactivate network control again.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
114
Network control active
(from version 02.00)
TRUE if the network control is requested via bit 5 of the AC drive control
word 0x400B:001 (P592.01). Otherwise FALSE.
Notes:
Set this selection if the network control is to be activated via bit 5 of
the AC drive control word.
The AC drive control word can be used with any communication
pro
tocol.
 AC Drive Profile

188
0x2631:043
(P400.43)
Function list: Activate fault 1
(Function list: Fault 1)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate fault 1" function.
Trigger = TRUE: Trigger user-defined error 1.
Trigger = FALSE: no action.
Notes:
After the error is triggered, the motor is brought to a standstill with
the quick stop ramp. The inverter is then disabled.
Associated error code:
25217 | 0x6281 User-defined fault 1
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:044
(P400.44)
Function list: Activate fault 2
(Function list: Fault 2)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate fault 2" function.
Trigger = TRUE: Trigger user-defined error 2.
Trigger = FALSE: no action.
Notes:
After the error is triggered, the motor is brought to a standstill with
the quick stop ramp. The inverter is then disabled.
Associated error code:
25218 | 0x6282 User-defined fault 2
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2634:010
(P420.10)
Digital outputs function: NetWordOUT1 bit 0
(Dig.out.function: NetWordOUT1.00)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 0 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
51
Ready for operation
TRUE if inverter is ready for operation (no error active, no STO active
and DC-bus voltage ok). Otherwise FALSE.
0x2634:011
(P420.11)
Digital outputs function: NetWordOUT1 bit 1
(Dig.out.function: NetWordOUT1.01)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 1 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2634:012
(P420.12)
Digital outputs function: NetWordOUT1 bit 2
(Dig.out.function: NetWordOUT1.02)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 2 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
52
Operation enabled
TRUE if inverter and start are enabled. Otherwise FALSE.
0x2634:013
(P420.13)
Digital outputs function: NetWordOUT1 bit 3
(Dig.out.function: NetWordOUT1.03)
For further possible settings, see parameter
0x2634:001 (P420.01).  429
Assignment of a trigger to bit 3 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
56
Error active
TRUE if error is active. Otherwise FALSE.
0x2634:014
(P420.14)
Digital outputs function: NetWordOUT1 bit 4
(Dig.out.function: NetWordOUT1.04)
For further possible settings, see parameter
0x2634:001 (P420.01).  429
Assignment of a trigger to bit 4 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
