Parameter
Name / value range / [default setting]
Info
0x2634:015
(P420.15)
Digital outputs function: NetWordOUT1 bit 5
(Dig.out.function: NetWordOUT1.05)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 5 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
54
Quick stop active
TRUE if quick stop is active. Otherwise FALSE.
0x2634:016
(P420.16)
Digital outputs function: NetWordOUT1 bit 6
(Dig.out.function: NetWordOUT1.06)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 6 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
50
Running
TRUE if inverter and start are enabled and output frequency > 0.2 Hz.
Otherwise FALSE.
0x2634:017
(P420.17)
Digital outputs function: NetWordOUT1 bit 7
(Dig.out.function: NetWordOUT1.07)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 7 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
58 Device warning active TRUE if warning is active. Otherwise FALSE.
A warning has no impact on the operating status of the inverter.
A warning is reset automatically if the cause has been eliminated.
0x2634:018
(P420.18)
Digital outputs function: NetWordOUT1 bit 8
(Dig.out.function: NetWordOUT1.08)
For further possible settings, see parameter
0x2634:001 (P420.01).  429
Assignment of a trigger to bit 8 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2634:019
(P420.19)
Digital outputs function: NetWordOUT1 bit 9
(Dig.out.function: NetWordOUT1.09)
For further possible settings, see parameter
0x2634:001 (P420.01).  429
Assignment of a trigger to bit 9 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2634:020
(P420.20)
Digital outputs function: NetWordOUT1 bit 10
(Dig.out.function: NetWordOUT1.10)
For further possible settings, see parameter
0x2634:001 (P420.01).  429
Assignment of a trigger to bit 10 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
72
Setpoint speed reached
TRUE if frequency setpoint reached. Otherwise FALSE.
0x2634:021
(P420.21)
Digital outputs function: NetWordOUT1 bit 11
(Dig.out.function: NetWordOUT1.11)
For further possible settings, see parameter
0x2634:001 (P420.01).  429
Assignment of a trigger to bit 11 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
78
Current limit reached
TRUE if current motor current ≥ maximum current. Otherwise FALSE.
Display of the present motor current in 0x2D88 (P104.00).
Setting for the maximum current in 0x6073 (P324.00).
0x2634:022
(P420.22)
Digital outputs function: NetWordOUT1 bit 12
(Dig.out.function: NetWordOUT1.12)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 12 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
71
Actual speed = 0
TRUE if current output frequency = 0 Hz (± 0.01 Hz), irrespective of the
operating mode. Otherwise FALSE.
Display of the current output frequency in 0x2DDD (P100.00).
0x2634:023
(P420.23)
Digital outputs function: NetWordOUT1 bit 13
(Dig.out.function: NetWordOUT1.13)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 13 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
69
Rotational direction reversed
TRUE if output frequency is negative. Otherwise FALSE.
