Emotron VS10 - Page 438

438 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2631:036
(P400.36)
Function list: Abort sequence
(Function list: Seq: Abort)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Abort sequence" function.
Trigger = FALSE↗TRUE (edge): Abort sequence.
Trigger = TRUE↘FALSE (edge): No action.
Notes:
This function serves to directly stop the sequence without the final
segment being executed. In this case, the standard setpoint or the
setpoint source selected via setpoint change-over is active again.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:050
(P400.50)
Function list: Select sequence (bit 0)
(Function list: Seq: Select. b0)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Select sequence (bit 0)" function.
Selection bit with the valency 2
0
for bit coded selection of a sequence.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
The selected sequence is not started automatically.
For a status-controlled start, the function "Run/abort sequence"
0x2631:030 (P400.30) is available.
For an edge-controlled start, the function "Start sequence"
0x2631:031 (P400.31) is available.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:051
(P400.51)
Function list: Select sequence (bit 1)
(Function list: Seq: Select. b1)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Select sequence (bit 1)" function.
Selection bit with the valency 2
1
for the bit-coded selection of a
sequence.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
The selected sequence is not started automatically.
For a status-controlled start, the function "Run/abort sequence"
0x2631:030 (P400.30) is available.
For an edge-controlled start, the function "Start sequence"
0x2631:031 (P400.31) is available.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:052
(P400.52)
Function list: Select sequence (bit 2)
(Function list: Seq: Select. b2)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Select sequence (bit 2)" function.
Selection bit with the valency 2
2
for the bit-coded selection of a
sequence.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
The selected sequence is not started automatically.
For a status-controlled start, the function "Run/abort sequence"
0x2631:030 (P400.30) is available.
For an edge-controlled start, the function "Start sequence"
0x2631:031 (P400.31) is available.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:053
(P400.53)
Function list: Select sequence (bit 3)
(Function list: Seq: Select. b3)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Select sequence (bit 3)" function.
Selection bit with the valency 2
3
for the bit-coded selection of a
sequence.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
The selected sequence is not started automatically.
For a status-controlled start, the function "Run/abort sequence"
0x2631:030 (P400.30) is available.
For an edge-controlled start, the function "Start sequence"
0x2631:031 (P400.31) is available.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
