Emotron VS10 - Page 437

Parameter
Name / value range / [default setting]
Info
0x2631:030
(P400.30)
Function list: Run/abort sequence
(Function list: Seq: Run/abort)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Run/abort sequence" function.
Trigger = TRUE: Start selected sequence.
Trigger = FALSE: Abort sequence.
Notes:
The assigned trigger must remain set to TRUE for the duration of the
sequence.
If the trigger bit is reset to FALSE, the sequence is aborted. In this
case, the standard setpoint or the setpoint source selected via
setpoint change-over is active again.
A sequence is selected in a binary-coded fashion via the trigger
assigned to the four functions "Select sequence (bit 0)" 0x2631:050
(P400.50) ... "Select sequence (bit 3)" 0x2631:053 (P400.53).
For an edge-controlled start, the function "Start sequence"
0x2631:031 (P400.31) is optionally available.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:031
(P400.31)
Function list: Start sequence
(Function list: Seq: Start)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Start sequence" function.
Trigger = FALSE↗TRUE (edge): Start selected sequence.
Trigger = TRUE↘FALSE (edge): No action.
Notes:
After the start, the sequencer remains activated until the function
"Stop sequence" 0x2631:035 (P400.35) or the function "Abort
sequence" 0x2631:036 (P400.36) is executed. A normal stop
command does not reset the start command for the sequencer.
For a status-controlled start, the function "Run/abort sequence"
0x2631:030 (P400.30) is optionally available.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:032
(P400.32)
Function list: Next sequence step
(Function list: Seq: Next step)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Next sequence step" function.
Trigger = FALSE↗TRUE (edge): Next sequence step.
Trigger = TRUE↘FALSE (edge): No action.
Notes:
The execution of the current step is completed even if the time
para
meterised for the segment has not elapsed yet.
The function is only relevant for Sequencer mode 0x4025 (P800.00) =
"Step operation [2]" or "Time & step operation [3]".
A jump to the next sequence step is not possible if the sequence
pau
ses, the sequence is suspended or the final segment is executed.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:033
(P400.33)
Function list: Pause sequence
(Function list: Seq: Pause)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Pause sequence" function.
Trigger = TRUE: Pause sequence.
Trigger = FALSE: Continue sequence.
Notes:
During the pause, the sequence stops in the current step. The
expira
tion of the time set for the segment is stopped.
The sequencer setpoint continues to remain active.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:034
(P400.34)
Function list: Suspend sequence
(Function list: Seq: Suspense)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Suspend sequence" function.
Trigger = TRUE: Suspend sequence.
Trigger = FALSE: Continue sequence.
Notes:
This function serves to temporarily change over to the standard
set
point or the setpoint source selected via setpoint change-over.
The sequence is continued at the point where it was suspended.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:035
(P400.35)
Function list: Stop sequence
(Function list: Seq: Stop)
Setting can only be changed if the inverter is
inhibi
ted.
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Stop sequence" function.
Trigger = FALSE↗TRUE (edge): Stop sequence.
Trigger = TRUE↘FALSE (edge): No action.
Notes:
If the sequence is stopped, it is jumped to the final segment.
The further execution depends on the selected End of sequence
mode 0x402F (P824.00).
0
Not connected
No trigger assigned (trigger is constantly FALSE).
