Emotron VS10 - Page 51

Display code
Short designation
Default setting
Setting range
Address
Category
└ P308.01
Max.load.for 60s
150 %
30 ... 200 %
0x2D4B:001
general
└ P308.02 Speed comp. On [0] Selection list 0x2D4B:002 general
└ P308.03
Response
Fault [3]
Selection list
0x2D4B:003
general
P310.xx
Mot.phase.fail.
└ P310.01
Response
No response [0]
Selection list
0x2D45:001
general
└ P310.02
Current thresh.
5.0 %
1.0 ... 25.0 %
0x2D45:002
general
└ P310.03 Voltage thresh. 10.0 V 0.0 ... 100.0 V 0x2D45:003 general
P315.xx
Slip compens.
└ P315.01
Slip: gain
100.00 %
-200.00 ... 200.00 %
0x2B09:001
general
└ P315.02
Filter time
5 ms
1 ... 6000 ms
0x2B09:002
general
P316.xx
V/f boosts
└ P316.01 Fixed V/f boost 2.5 % * 0.0 ... 20.0 % 0x2B12:001 MCTRL
└ P316.02
Dynam. V/f boost
0.0 %
0.0 ... 20.0 %
0x2B12:002
general
P317.xx
Skip frequencies
└ P317.01
Skip frequency 1
0.0 Hz
0.0 ... 599.0 Hz
0x291F:001
general
└ P317.02
Skip bandwidth 1
0.0 Hz
0.0 ... 10.0 Hz
0x291F:002
general
└ P317.03 Skip frequency 2 0.0 Hz 0.0 ... 599.0 Hz 0x291F:003 general
└ P317.04
Skip bandwidth 2
0.0 Hz
0.0 ... 10.0 Hz
0x291F:004
general
└ P317.05
Skip frequency 3
0.0 Hz
0.0 ... 599.0 Hz
0x291F:005
general
└ P317.06
Skip bandwidth 3
0.0 Hz
0.0 ... 10.0 Hz
0x291F:006
general
P318.xx
Oscillat. damp.
└ P318.01 Gain 20 % -100 ... 100 % 0x2B0A:001 MCTRL
└ P318.02
Filter time
5 ms
1 ... 600 ms
0x2B0A:002
MCTRL
P319.00
Field weak thold
0.0 Hz
-599.0 ... 599.0 Hz
0x2B0C
general
P320.xx
Motor parameters
└ P320.04
Rated speed
Device for 50-Hz mains:
1450 rpm
Device for 60-Hz mains:
1750 rpm
50 ... 50000 rpm
0x2C01:004
MCTRL
└ P320.05
Rated frequency
Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
1.0 ... 1000.0 Hz
0x2C01:005
MCTRL
└ P320.06
Rated power
0.25 kW *
0.00 ... 655.35 kW
0x2C01:006
MCTRL
└ P320.07
Rated voltage
230 V *
0 ... 65535 V
0x2C01:007
MCTRL
└ P320.08 Cosine phi 0.80 0.00 ... 1.00 0x2C01:008 MCTRL
P322.00
Max motor speed
6075 rpm
0 ... 480000 rpm
0x6080
general
P323.00
Motor current
1.700 A *
0.001 ... 500.000 A
0x6075
MCTRL
P324.00
Max current
200.0 %
0.0 ... 3000.0 %
0x6073
general
P325.00
Motor torque
1.650 Nm *
0.001 ... 1000.000 Nm
0x6076
MCTRL
P326.00 Max torque 250.0 % 0.0 ... 3000.0 % 0x6072 general
└ P327.04
Identify mot.
0
0 ... 1
0x2822:004
general
└ P327.05
Calibrate mot.
0
0 ... 1
0x2822:005
general
P329.xx
MaxTrq.Monitor
└ P329.01
Response
No response [0]
Selection list
0x2D67:001
MCTRL
└ P329.02 Triggering delay 0.000 s 0.000 ... 10.000 s 0x2D67:002 MCTRL
P330.xx
VFC-ECO
└ P330.01
Min. voltage
20 %
20 ... 100 %
0x2B0D:001
MCTRL
P332.xx
Speed controller
└ P332.01
Gain
0.00193 Nm/rpm *
0.00000 ...
20000.00000 Nm/rpm
0x2900:001
MCTRL
