52 01-6203-01R3, CG Drives & Automation
Display code
Short designation
Default setting
Setting range
Address
Category
└ P332.02
Reset time
80.0 ms *
1.0 ... 6000.0 ms
0x2900:002
MCTRL
P333.xx V/f Imax contr.
└ P333.01
Gain
0.284 Hz/A *
0.000 ... 1000.000 Hz/A
0x2B08:001
MCTRL
└ P333.02
Reset time
2.3 ms *
1.0 ... 2000.0 ms
0x2B08:002
MCTRL
P334.xx
Current contr.
└ P334.01
Gain
42.55 V/A *
0.00 ... 750.00 V/A
0x2942:001
MCTRL
└ P334.02 Reset time 4.50 ms * 0.01 ... 2000.00 ms 0x2942:002 MCTRL
P335.xx
Moment of inert.
└ P335.01
Motor inertia
3.70 kg cm² *
0.00 ... 20000000.00 kg cm²
0x2910:001
MCTRL
└ P335.02
Load inertia
3.70 kg cm² *
0.00 ... 20000000.00 kg cm²
0x2910:002
MCTRL
└ P336.02
Ramp time
1.0 s
0.0 ... 60.0 s
0x2948:002
general
P337.xx
└ P337.01
Pos. torqlim src
Max torque [0]
Selection list
0x2949:001
general
└ P337.02
Neg. torqlim src
(-) Max torque [0]
Selection list
0x2949:002
general
└ P337.03
Act postorqlim
x.x %
(Read only)
0x2949:003
general
└ P337.04
Act negtorqlim
x.x %
(Read only)
0x2949:004
general
P340.xx Speed limitation
└ P340.01
Upper limit
0 vel. unit
-480000 ... 480000 vel. unit
0x2946:001
general
└ P340.02
Lower limit
0 vel. unit
-480000 ... 480000 vel. unit
0x2946:002
general
└ P340.03
Uppspeed lim src
Max. frequency [0]
Selection list
0x2946:003
general
└ P340.04
Lowspeed lim src
(-) Max. freq. [0]
Selection list
0x2946:004
general
└ P340.05 Upper freq.limit Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
-1000.0 ... 1000.0 Hz 0x2946:005 general
└ P340.06
Lower freq.limit
Device for 50-Hz mains:
-50.0 Hz
Device for 60-Hz mains:
-60.0 Hz
-1000.0 ... 1000.0 Hz
0x2946:006
general
└ P340.07
Act uppspeed lim
x.x Hz
(Read only)
0x2946:007
general
└ P340.08 Act lowspeed lim x.x Hz (Read only) 0x2946:008 general
P350.xx
Overspeed monit.
└ P350.01
Threshold
8000 rpm
50 ... 50000 rpm
0x2D44:001
general
└ P350.02
Response
Fault [3]
Selection list
0x2D44:002
general
P351.xx
ASM motor par.
└ P351.01 Rotor resistance 8.8944 Ω * 0.0000 ... 200.0000 Ω 0x2C02:001 MCTRL
└ P351.02
Mutual induct.
381.9 mH *
0.0 ... 50000.0 mH
0x2C02:002
MCTRL
└ P351.03
Magn. current
0.96 A *
0.00 ... 500.00 A
0x2C02:003
MCTRL
└ P351.04
Slip frequency
x.x Hz
(Read only)
0x2C02:004
general
P352.xx
PSM motor par.
└ P352.01 BEMF constant 41.8 V/1000rpm 0.0 ... 100000.0 V/1000rpm 0x2C03:001 MCTRL
P353.xx
Overcurr. monit.
└ P353.01
Threshold
6.8 A *
0.0 ... 1000.0 A
0x2D46:001
general
└ P353.02
Response
Fault [3]
Selection list
0x2D46:002
general
P354.00
Voltage reserve
5 %
1 ... 20 %
0x29E4
general
P400.xx Function list
└ P400.01
Enable inverter
TRUE [1]
Selection list
0x2631:001
general
└ P400.02
Run
Digital input 1 [11]
Selection list
0x2631:002
general
└ P400.03
Quick stop
Not connected [0]
Selection list
0x2631:003
general
└ P400.04
Reset fault
Digital input 2 [12]
Selection list
0x2631:004
general
