Emotron VS10 - Page 53

Display code
Short designation
Default setting
Setting range
Address
Category
└ P400.05
DC braking
Not connected [0]
Selection list
0x2631:005
general
└ P400.06 Start forward Not connected [0] Selection list 0x2631:006 general
└ P400.07
Start reverse
Not connected [0]
Selection list
0x2631:007
general
└ P400.08
Run forward
Not connected [0]
Selection list
0x2631:008
general
└ P400.09
Run reverse
Not connected [0]
Selection list
0x2631:009
general
└ P400.10
Jog foward
Not connected [0]
Selection list
0x2631:010
general
└ P400.11 Jog reverse Not connected [0] Selection list 0x2631:011 general
└ P400.12
Keypad control
Not connected [0]
Selection list
0x2631:012
general
└ P400.13
Invert rotation
Digital input 3 [13]
Selection list
0x2631:013
general
└ P400.14
Setp: AI1
Not connected [0]
Selection list
0x2631:014
general
└ P400.15
Setp: AI2
Not connected [0]
Selection list
0x2631:015
general
└ P400.16 Setp: Keypad Not connected [0] Selection list 0x2631:016 general
└ P400.17
Setp: Network
Not connected [0]
Selection list
0x2631:017
general
└ P400.18
Setp: Preset b0
Digital input 4 [14]
Selection list
0x2631:018
general
└ P400.19
Setp: Preset b1
Digital input 5 [15]
Selection list
0x2631:019
general
└ P400.20
Setp: Preset b2
Not connected [0]
Selection list
0x2631:020
general
└ P400.21 Setp: Preset b3 Not connected [0] Selection list 0x2631:021 general
└ P400.23
MOP up
Not connected [0]
Selection list
0x2631:023
general
└ P400.24
MOP down
Not connected [0]
Selection list
0x2631:024
general
└ P400.25
Setp: MOP
Not connected [0]
Selection list
0x2631:025
general
└ P400.26
Setp: Segment b0
Not connected [0]
Selection list
0x2631:026
general
└ P400.27 Setp: Segment b1 Not connected [0] Selection list
0x2631:027
general
└ P400.28
Setp: Segment b2
Not connected [0]
Selection list
0x2631:028
general
└ P400.29
Setp: Segment b3
Not connected [0]
Selection list
0x2631:029
general
└ P400.30
Seq: Run/abort
Not connected [0]
Selection list
0x2631:030
general
└ P400.31
Seq: Start
Not connected [0]
Selection list
0x2631:031
general
└ P400.32 Seq: Next step Not connected [0] Selection list
0x2631:032
general
└ P400.33
Seq: Pause
Not connected [0]
Selection list
0x2631:033
general
└ P400.34
Seq: Suspense
Not connected [0]
Selection list
0x2631:034
general
└ P400.35
Seq: Stop
Not connected [0]
Selection list
0x2631:035
general
└ P400.36
Seq: Abort
Not connected [0]
Selection list
0x2631:036
general
└ P400.37 Network control Not connected [0] Selection list
0x2631:037
general
└ P400.39
Activ. ramp 2
Not connected [0]
Selection list
0x2631:039
general
└ P400.40
Load param.set
Not connected [0]
Selection list
0x2631:040
general
└ P400.41
Sel. paramset b0
Not connected [0]
Selection list
0x2631:041
general
└ P400.42
Sel. paramset b1
Not connected [0]
Selection list
0x2631:042
general
└ P400.43 Fault 1 Not connected [0] Selection list
0x2631:043
general
└ P400.44
Fault 2
Not connected [0]
Selection list
0x2631:044
general
└ P400.45
PID off
Not connected [0]
Selection list
0x2631:045
general
└ P400.46
PID output=0
Not connected [0]
Selection list
0x2631:046
general
└ P400.47
PID-I inhibited
Not connected [0]
Selection list
0x2631:047
general
└ P400.48 PID-Inf ramp on TRUE [1] Selection list
0x2631:048
general
└ P400.49
Release brake
Not connected [0]
Selection list
0x2631:049
general
└ P400.50
Seq: Select. b0
Not connected [0]
Selection list
0x2631:050
general
└ P400.51
Seq: Select. b1
Not connected [0]
Selection list
0x2631:051
general
└ P400.52
Seq: Select. b2
Not connected [0]
Selection list
0x2631:052
general
└ P400.53 Seq: Select. b3 Not connected [0] Selection list
0x2631:053
general
└ P400.54
PosCounter reset
Not connected [0]
Selection list
0x2631:054
general
