Emotron VS10 - Page 54

54 01-6203-01R3, CG Drives & Automation
Display code
Short designation
Default setting
Setting range
Address
Category
P410.xx
DI settings
└ P410.02 Input function Digital Input [0] Selection list 0x2630:002 general
P411.xx
DI inversion
└ P411.01
DI1 inversion
Not inverted [0]
Selection list
0x2632:001
general
└ P411.02
DI2 inversion
Not inverted [0]
Selection list
0x2632:002
general
└ P411.03
DI3 inversion
Not inverted [0]
Selection list
0x2632:003
general
└ P411.04 DI4 inversion Not inverted [0] Selection list 0x2632:004 general
└ P411.05
DI5 inversion
Not inverted [0]
Selection list
0x2632:005
general
P412.00
Freq. threshold
0.0 Hz
0.0 ... 599.0 Hz
0x4005
general
P413.00
MOP startmode
Last value [0]
Selection list
0x4003
general
P414.xx
MOP start value
└ P414.01 Frequency 0.0 Hz 0.0 ... 599.0 Hz 0x4004:001 general
└ P414.02
PID value
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4004:002
general
└ P414.03
Torque
0.0 %
0.0 ... 1000.0 %
0x4004:003
general
P420.xx
Dig.out.function
└ P420.01
Relay function
Rdy for operat. [51]
Selection list
0x2634:001
general
└ P420.02 DO1 function Release brake [115] Selection list 0x2634:002 general
└ P420.10
NetWordOUT1.00
Rdy for operat. [51]
Selection list
0x2634:010
general
└ P420.11
NetWordOUT1.01
Not connected [0]
Selection list
0x2634:011
general
└ P420.12
NetWordOUT1.02
Operat. enabled [52]
Selection list
0x2634:012
general
└ P420.13
NetWordOUT1.03
Error [56]
Selection list
0x2634:013
general
└ P420.14 NetWordOUT1.04 Not connected [0] Selection list 0x2634:014 general
└ P420.15
NetWordOUT1.05
Quick stop [54]
Selection list
0x2634:015
general
└ P420.16
NetWordOUT1.06
Running [50]
Selection list
0x2634:016
general
└ P420.17
NetWordOUT1.07
Device warning [58]
Selection list
0x2634:017
general
└ P420.18
NetWordOUT1.08
Not connected [0]
Selection list
0x2634:018
general
└ P420.19 NetWordOUT1.09 Not connected [0] Selection list
0x2634:019
general
└ P420.20
NetWordOUT1.10
Speed setp=act [72]
Selection list
0x2634:020
general
└ P420.21
NetWordOUT1.11
At current limit [78]
Selection list
0x2634:021
general
└ P420.22
NetWordOUT1.12
Actual speed=0 [71]
Selection list
0x2634:022
general
└ P420.23
NetWordOUT1.13
Rot.dir.reversed [69]
Selection list
0x2634:023
general
└ P420.24 NetWordOUT1.14 Release brake [115] Selection list
0x2634:024
general
└ P420.25
NetWordOUT1.15
Safe Torque Off [55]
Selection list
0x2634:025
general
P421.xx
DO inversion
└ P421.01
Relay inverted
Not inverted [0]
Selection list
0x2635:001
general
└ P421.02
DO1 inversion
Not inverted [0]
Selection list
0x2635:002
general
P430.xx Analog input 1
└ P430.01
AI1 input range
0 ... 10 VDC [0]
Selection list
0x2636:001
general
└ P430.02
AI1 freq @ min
0.0 Hz
-1000.0 ... 1000.0 Hz
0x2636:002
general
└ P430.03
AI1 freq @ max
Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
-1000.0 ... 1000.0 Hz
0x2636:003
general
└ P430.04
AI1 PID @ min
0.00 PID unit
-300.00 ... 300.00 PID unit
0x2636:004
general
└ P430.05
AI1 PID @ max
100.00 PID unit
-300.00 ... 300.00 PID unit
0x2636:005
general
└ P430.06
AI1 filter time
10 ms
0 ... 10000 ms
0x2636:006
general
└ P430.07
AI1 dead band
0.0 %
0.0 ... 100.0 %
0x2636:007
general
└ P430.08 AI1 monit.level 0.0 % -100.0 ... 100.0 % 0x2636:008 general
└ P430.09
AI1 monit.cond.
IN < threshold [0]
Selection list
0x2636:009
general
