Emotron VS10 - Page 55

Display code
Short designation
Default setting
Setting range
Address
Category
└ P430.10
AI1 error resp.
Fault [3]
Selection list
0x2636:010
general
└ P430.11 Min. torque 0.0 % -400.0 ... 400.0 % 0x2636:011 general
└ P430.12
Max. torque
100.0 %
-400.0 ... 400.0 %
0x2636:012
general
P431.xx
Analog input 2
└ P431.01
AI2 input range
0 ... 10 VDC [0]
Selection list
0x2637:001
general
└ P431.02
AI2 freq @ min
0.0 Hz
-1000.0 ... 1000.0 Hz
0x2637:002
general
└ P431.03 AI2 freq @ max Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
-1000.0 ... 1000.0 Hz 0x2637:003 general
└ P431.04
AI2 PID @ min
0.00 PID unit
-300.00 ... 300.00 PID unit
0x2637:004
general
└ P431.05
AI2 PID @ max
100.00 PID unit
-300.00 ... 300.00 PID unit
0x2637:005
general
└ P431.06 AI2 filter time 10 ms 0 ... 10000 ms 0x2637:006 general
└ P431.07
AI2 dead band
0.0 %
0.0 ... 100.0 %
0x2637:007
general
└ P431.08
AI2 monit.level
0.0 %
-100.0 ... 100.0 %
0x2637:008
general
└ P431.09
AI2 error resp.
IN < threshold [0]
Selection list
0x2637:009
general
└ P431.10
AI2 error resp.
Fault [3]
Selection list
0x2637:010
general
└ P431.11 Min. torque 0.0 % -400.0 ... 400.0 % 0x2637:011 general
└ P431.12
Max. torque
100.0 %
-400.0 ... 400.0 %
0x2637:012
general
P440.xx
Analog output 1
└ P440.01
AO1 outp. range
0 ... 10 VDC [1]
Selection list
0x2639:001
general
└ P440.02
AO1 function
Outp. frequency [1]
Selection list
0x2639:002
general
└ P440.03 AO1 min. signal 0 -2147483648 ... 2147483647 0x2639:003 general
└ P440.04
AO1 max. signal
1000
-2147483648 ... 2147483647
0x2639:004
general
P450.xx
Freq. presets
└ P450.01
Freq. preset 1
20.0 Hz
0.0 ... 599.0 Hz
0x2911:001
general
└ P450.02
Freq. preset 2
40.0 Hz
0.0 ... 599.0 Hz
0x2911:002
general
└ P450.03 Freq. preset 3 Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
0.0 ... 599.0 Hz
0x2911:003
general
└ P450.04
Freq. preset 4
0.0 Hz
0.0 ... 599.0 Hz
0x2911:004
general
└ P450.05
Freq. preset 5
0.0 Hz
0.0 ... 599.0 Hz
0x2911:005
general
└ P450.06
Freq. preset 6
0.0 Hz
0.0 ... 599.0 Hz
0x2911:006
general
└ P450.07 Freq. preset 7 0.0 Hz 0.0 ... 599.0 Hz
0x2911:007
general
└ P450.08
Freq. preset 8
0.0 Hz
0.0 ... 599.0 Hz
0x2911:008
general
└ P450.09
Freq. preset 9
0.0 Hz
0.0 ... 599.0 Hz
0x2911:009
general
└ P450.10
Freq. preset 10
0.0 Hz
0.0 ... 599.0 Hz
0x2911:010
general
└ P450.11
Freq. preset 11
0.0 Hz
0.0 ... 599.0 Hz
0x2911:011
general
└ P450.12 Freq. preset 12 0.0 Hz 0.0 ... 599.0 Hz
0x2911:012
general
└ P450.13
Freq. preset 13
0.0 Hz
0.0 ... 599.0 Hz
0x2911:013
general
└ P450.14
Freq. preset 14
0.0 Hz
0.0 ... 599.0 Hz
0x2911:014
general
└ P450.15
Freq. preset 15
0.0 Hz
0.0 ... 599.0 Hz
0x2911:015
general
P451.xx
PID presets
└ P451.01 PID preset 1 0.00 PID unit -300.00 ... 300.00 PID unit 0x4022:001 general
└ P451.02
PID preset 2
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4022:002
general
└ P451.03
PID preset 3
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4022:003
general
└ P451.04
PID preset 4
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4022:004
general
└ P451.05
PID preset 5
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4022:005
general
└ P451.06 PID preset 6 0.00 PID unit -300.00 ... 300.00 PID unit 0x4022:006 general
