56 01-6203-01R3, CG Drives & Automation
Display code
Short designation
Default setting
Setting range
Address
Category
└ P451.07
PID preset 7
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4022:007
general
└ P451.08 PID preset 8 0.00 PID unit -300.00 ... 300.00 PID unit 0x4022:008 general
P452.xx
Torque presets
└ P452.01
Torque preset 1
100.0 %
-400.0 ... 400.0 %
0x2912:001
general
└ P452.02
Torque preset 2
100.0 %
-400.0 ... 400.0 %
0x2912:002
general
└ P452.03
Torque preset 3
100.0 %
-400.0 ... 400.0 %
0x2912:003
general
└ P452.04 Torque preset 4 100.0 % -400.0 ... 400.0 % 0x2912:004 general
└ P452.05
Torque preset 5
100.0 %
-400.0 ... 400.0 %
0x2912:005
general
└ P452.06
Torque preset 6
100.0 %
-400.0 ... 400.0 %
0x2912:006
general
└ P452.07
Torque preset 7
100.0 %
-400.0 ... 400.0 %
0x2912:007
general
└ P452.08
Torque preset 8
100.0 %
-400.0 ... 400.0 %
0x2912:008
general
P500.xx Module ID
└ P500.01
Active module ID
-
(Read only)
0x231F:001
general
└ P500.02
Module ID conn.
-
(Read only)
0x231F:002
general
P505.xx
NetWordIN1 fct.
└ P505.01
NetWordIN1.00
Not active [0]
Selection list
0x400E:001
general
└ P505.02 NetWordIN1.01 Not active [0] Selection list 0x400E:002 general
└ P505.03
NetWordIN1.02
Quick stop [3]
Selection list
0x400E:003
general
└ P505.04
NetWordIN1.03
Not active [0]
Selection list
0x400E:004
general
└ P505.05
NetWordIN1.04
Run forward [8]
Selection list
0x400E:005
general
└ P505.06
NetWordIN1.05
Setp: Preset b0 [18]
Selection list
0x400E:006
general
└ P505.07 NetWordIN1.06 Setp: Preset b1 [19] Selection list 0x400E:007 general
└ P505.08
NetWordIN1.07
Reset error [4]
Selection list
0x400E:008
general
└ P505.09
NetWordIN1.08
Not active [0]
Selection list
0x400E:009
general
└ P505.10
NetWordIN1.09
DC braking [5]
Selection list
0x400E:010
general
└ P505.11
NetWordIN1.10
Not active [0]
Selection list
0x400E:011
general
└ P505.12 NetWordIN1.11 Not active [0] Selection list 0x400E:012 general
└ P505.13
NetWordIN1.12
Invert rotation [13]
Selection list
0x400E:013
general
└ P505.14
NetWordIN1.13
Not active [0]
Selection list
0x400E:014
general
└ P505.15
NetWordIN1.14
Not active [0]
Selection list
0x400E:015
general
└ P505.16
NetWordIN1.15
Not active [0]
Selection list
0x400E:016
general
P508.00 CANopen comm. No action [0] Selection list
0x2300
CANopen
P508.00
Modbus comm.
No action [0]
Selection list
0x2320
Modbus RTU
P509.00
CANopen switch
-
(Read only)
0x2303
CANopen
P509.00
Modbus switch
-
(Read only)
0x2323
Modbus RTU
P510.xx
CANopen sett.
└ P510.01 Node ID 1 1 ... 127 0x2301:001 CANopen
└ P510.02
Baud rate
500 kbps [5]
Selection list
0x2301:002
CANopen
└ P510.03
Slave/Master
Slave [0]
Selection list
0x2301:003
CANopen
└ P510.04
Start rem. delay
3000 ms
0 ... 65535 ms
0x2301:004
CANopen
└ P510.05
SDO2 channel
Not active [0]
Selection list
0x2301:005
CANopen
└ P510.06 COB-ID Config Base + node-ID [0] Selection list 0x2301:006 CANopen
P510.xx
Modbus sett.
└ P510.01
Node ID
1
1 ... 247
0x2321:001
Modbus RTU
└ P510.02
Baud rate
Automatic [0]
Selection list
0x2321:002
Modbus RTU
└ P510.03
Data format
Automatic [0]
Selection list
0x2321:003
Modbus RTU
└ P510.04 Min. resp. time 0 ms 0 ... 1000 ms 0x2321:004 Modbus RTU
P511.xx
CANopen diag.
