Emotron VS10 - Page 57

Display code
Short designation
Default setting
Setting range
Address
Category
└ P511.01
Active node ID
-
(Read only)
0x2302:001
CANopen
└ P511.02 Active baud rate - (Read only) 0x2302:002 CANopen
P511.xx
Modbus diag.
└ P511.01
Active node ID
-
(Read only)
0x2322:001
Modbus RTU
└ P511.02
Active baud rate
-
(Read only)
0x2322:002
Modbus RTU
└ P511.03
Data format
-
(Read only)
0x2322:003
Modbus RTU
P515.00 Time-out status - (Read only) 0x2307 CANopen
P515.xx
Modbus monit.
└ P515.01
Resp. Time-out
Fault [3]
Selection list
0x2858:001
Modbus RTU
└ P515.02
Time-out time
2.0 s
0.0 ... 300.0 s
0x2858:002
Modbus RTU
P516.00
CANopen status
-
(Read only)
0x2308
CANopen
P517.00 CAN contr.status - (Read only) 0x2309 CANopen
P518.00
CAN errorcounter
-
(Read only)
0x230B
CANopen
P520.xx
Cons. heartbeat
└ P520.00
Highest subindex
-
(Read only)
0x1016:000
CANopen
└ P520.01
Cons. heartbeat1
0x00000000
0x00000000 ... 0x00FFFFFF
0x1016:001
CANopen
└ P520.02 Cons. heartbeat2 0x00000000 0x00000000 ... 0x00FFFFFF 0x1016:002 CANopen
└ P520.03
Cons. heartbeat3
0x00000000
0x00000000 ... 0x00FFFFFF
0x1016:003
CANopen
└ P520.04
Cons. heartbeat4
0x00000000
0x00000000 ... 0x00FFFFFF
0x1016:004
CANopen
P522.00
Prod. heartbeat
0 ms
0 ... 65535 ms
0x1017
CANopen
P530.xx
Para. mapping
└ P530.01 Parameter 1 0x00000000 0x00000000 ... 0xFFFFFF00 0x232B:001 Modbus RTU
└ P530.02
Parameter 2
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:002
Modbus RTU
└ P530.03
Parameter 3
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:003
Modbus RTU
└ P530.04
Parameter 4
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:004
Modbus RTU
└ P530.05
Parameter 5
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:005
Modbus RTU
└ P530.06 Parameter 6 0x00000000 0x00000000 ... 0xFFFFFF00 0x232B:006 Modbus RTU
└ P530.07
Parameter 7
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:007
Modbus RTU
└ P530.08
Parameter 8
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:008
Modbus RTU
└ P530.09
Parameter 9
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:009
Modbus RTU
└ P530.10
Parameter 10
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:010
Modbus RTU
└ P530.11 Parameter 11 0x00000000 0x00000000 ... 0xFFFFFF00 0x232B:011 Modbus RTU
└ P530.12
Parameter 12
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:012
Modbus RTU
└ P530.13
Parameter 13
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:013
Modbus RTU
└ P530.14
Parameter 14
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:014
Modbus RTU
└ P530.15
Parameter 15
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:015
Modbus RTU
└ P530.16 Parameter 16 0x00000000 0x00000000 ... 0xFFFFFF00 0x232B:016 Modbus RTU
└ P530.17
Parameter 17
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:017
Modbus RTU
└ P530.18
Parameter 18
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:018
Modbus RTU
└ P530.19
Parameter 19
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:019
Modbus RTU
└ P530.20
Parameter 20
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:020
Modbus RTU
└ P530.21 Parameter 21 0x00000000 0x00000000 ... 0xFFFFFF00
0x232B:021
Modbus RTU
└ P530.22
Parameter 22
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:022
Modbus RTU
└ P530.23
Parameter 23
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:023
Modbus RTU
└ P530.24
Parameter 24
0x00000000
0x00000000 ... 0xFFFFFF00
0x232B:024
Modbus RTU
P531.xx
Reg. assigned
└ P531.01 Register 1 - (Read only) 0x232C:001 Modbus RTU
└ P531.02
Register 2
-
(Read only)
0x232C:002
Modbus RTU
